Technical Data:
Width: 375 MM
Inlet Diameter: 127 MM
Outlet Diameter: 127 MM
Body Diameter Maximum: 299.97 MM
Body Length: 392 MM
Rated Flow LR: 11 CMM
Rated Flow MR: 12.9 CMM
Rated Flow HR: 14.6 CMM
Restriction LR: 152 MM H2O
Restriction MR: 203 MM H2O
Restriction HR: 254 MM H2O
Style: Tubular
Family: STG
Brand: Donaclone™
Accessories:
CUVE GASKET 12" FW SB SDG SDA
CUVE 12" QUICK REL.
VACUATOR VALVE
FILTRE A AIR SECURITE
ELEMENT
ELEMENT
ATTACHE
DROP TUBE
ADAPTATEUR, DUST DUMPA
| 1 | EIMCO - 04710001 (G120332) |
| 1 | HAVAM - HD9790 (G120332) |
| 1 | LEROI - GD1415937 (G120332) |
| 1 | MI-JACK - 37216704SUB (G120332) |
| 1 | SANDVIK - 04710001 (G120332) |
| 1 | TAMROCK - 04710001 (G120332) |
| 1 | WALGAHN-MOTORENTECHN - 00810128 (G120332) |
| 1 | WALGAHN-MOTORENTECHN - 810128 (G120332) |
| 1 | TEREX - 9018191 (G120332) |
| 1 | CASE/CASE IH - P0850553 (G120332) |
| 1 | NEW HOLLAND - P0850553 (G120332) |
| 1 | TEREX - P0850553 (G120332) |
| 1 | CASE/CASE IH - A075060 (G120332) |
| 1 | CASE/CASE IH - P850553 (G120332) |
| 1 | CATERPILLAR - 1X8139 (G120332) |
| 1 | CHAMPION ROAD - 15914 (G120332) |
| 1 | DRILTECH - 4710001 (G120332) |
