Données techniques :
Inlet Diameter: 127.64 MM Outlet Diameter: 127.64 MM Body Diameter Maximum: 300.7 MM Body Length: 654 MM Overall Length: 804.9 MM Rated Flow LR: 49.9 CMM Rated Flow MR: 69.3 CMM Rated Flow HR: 69.3 CMM Back Pressure Low-Range: 25 MM HG Back Pressure Mid-Range: 51 MM HG Back Pressure High-Range: 51 MM HG Attenuation LR: 12 DBA Attenuation HR: 18 DBA Inlet Clock Position: 6:00 Style: Style 3/Style 4
