Technical Data:
Inlet Diameter: 127.64 MM
Outlet Diameter: 127.64 MM
Body Diameter Maximum: 300.7 MM
Body Length: 654 MM
Overall Length: 804.9 MM
Rated Flow LR: 49.9 CMM
Rated Flow MR: 69.3 CMM
Rated Flow HR: 69.3 CMM
Back Pressure Low-Range: 25 MM HG
Back Pressure Mid-Range: 51 MM HG
Back Pressure High-Range: 51 MM HG
Attenuation LR: 12 DBA
Attenuation HR: 18 DBA
Inlet Clock Position: 6:00
Style: Style 3/Style 4
Accessories:
| 1 | NELSON - 201577N (M120749) |
| 1 | PRINOTH - 114666460 (M120749) |
| 1 | SEAGRAVE - P3423079 (M120749) |
